Intel Core i5-11600K

Intel Core i5-11600K

Product Collection : 11th Generation Intel® Core™ i5 Processors
Code Name : Products formerly Rocket Lake
Vertical Segment : Desktop
Processor Number : i5-11600K
Status : Launched
Launch Date : Q1'21
Lithography : 14 nm
Use Conditions : PC/Client/Tablet
# of Cores : 6
# of Threads : 12
Processor Base Frequency : 3.90 GHz
Max Turbo Frequency : 4.90 GHz
Cache : 12 MB Intel® Smart Cache
Bus Speed : 8 GT/s
Intel® Turbo Boost Technology 2.0 Frequency : 4.90 GHz
TDP : 125 W
Configurable TDP-down Frequency : 3.60 GHz
Configurable TDP-down : 95 W
Embedded Options Available : No
Max Memory Size (dependent on memory type) : 128 GB
Memory Types : DDR4-3200
Max # of Memory Channels : 2
Max Memory Bandwidth : 50 GB/s
ECC Memory Supported : No
Processor Graphics ‡ Intel® UHD Graphics 750
Graphics Base Frequency 350 MHz
Graphics Max Dynamic Frequency 1.30 GHz
Graphics Video Max Memory 64 GB
Execution Units 32
4K Support Yes, at 60Hz
Max Resolution (HDMI)‡ 4096x2160@60Hz
Max Resolution (DP)‡ 5120 x 3200 @60Hz
Max Resolution (eDP - Integrated Flat Panel)‡ 5120 x 3200 @60Hz
DirectX* Support 12.1
OpenGL* Support 4.5
Intel® Quick Sync Video Yes
Intel® InTru™ 3D Technology Yes
Intel® Clear Video HD Technology Yes
Intel® Clear Video Technology Yes
# of Displays Supported ‡ 3
Device ID 0x4C8A
OpenCL* Support 3.0
Scalability : 1S Only
PCI Express Revision : 4.0
PCI Express Configurations : Up to 1x16+1x4, 2x8+1x4, 1x8+3x4
Max # of PCI Express Lanes : 20
Sockets Supported : FCLGA1200
Max CPU Configuration : 1
Thermal Solution Specification : PCG 2019A
TJUNCTION : 100°C
Package Size : 37.5mm x 37.5mm
